ISO 13431-1999 GB/T 17637-1998 Compliant Geotextile Tensile Creep Testing Machine with 180KN Maximum Load for Geotextiles Tensile Creep Rupture

Name: ISO 134311999 GBT 176371998 Compliant Geotextile Tensile Creep Testing Machine with 180KN Maximum Load for Geotextiles Tensile Creep Rupture
Brand: Lonroy
Price: 1 USD

ISO 13431-1999 GB/T 17637-1998 Compliant Geotextile Tensile Creep Testing Machine with 180KN Maximum Load for Geotextiles Tensile Creep Rupture Manufactures

Brand Name : Lonroy

Place of Origin : China

MOQ : 1

Maximum load : 180KN

Load accuracy : ≤ ±1%

Fixture width : 50mm or 200mm

Effective creep space : 900mm

Effective test width : 350mm

Displacement accuracy : 0.03mm

Time measurement error : ≤ ±1%

Overall dimensions : 2300×550×1850mm (L×W×H)

Voltage : 220 V

Protection class : IP56

Sampling rate : High

A/D converter : High-precision

Measurement range : Wide

Test curves : Real-time display

Data storage : Yes

Certification : ISO ASTM CE

Price : Negotaible

Packaging Details : Wooden package

Delivery Time : 5-8 work days

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 200

Contact Now

ISO 13431 Geotextile Tensile Creep Testing Machine Geotextiles Tensile Creep Rupture Properties Tester

Product Description

Scope of application

It is used for the determination of tensile creep and tensile creep rupture properties of geotextiles and related products. It is mainly applied to the determination of tensile creep and tensile creep rupture properties of geotextiles and related products.

Complies with standards

Applicable to ISO 13431-1999 and GB/T 17637-1998 standards.

Main features

1. Real-time display of test curves, storage and analysis of measured data, and printing of report curves.

2. High sampling rate, resulting in more accurate test data.

3. Utilizes high-precision A/D converter, truly achieving continuous measurement without step changes, and a wider measurement range.

4. Has automatic fracture detection, automatic shutdown, and return-to-waiting functions.

5. Features multiple protection methods, ensuring the safety and reliability of the test operation.

6. Possesses flexible and diverse interfaces and control methods, allowing the drawing of various characteristic curves.

ISO 13431 Geotextile Tensile Creep Testing Machine Geotextiles Tensile Creep Rupture Properties Tester

Technical Specification

Maximum load	180KN
Load accuracy	≤ ±1%
Fixture width options	50mm or 200mm
Effective creep space	900mm
Effective test width	350mm
Displacement measurement accuracy	0.03mm
Time measurement error	≤ ±1%
Overall dimensions	2300×550×1850mm (L×W×H)
